PLC SPLITTER : 1x2

About PLC SPLITTER : 1x2

1.General Overview

• Product Name: Fiber PLC Splitter 1x2

• Application: Designed for splitting optical signals in fiber optic communication systems, such as FTTH, PON, and CATV networks.

• Key Features:

  • 1x2 configuration for signal splitting.

  • Planar Lightwave Circuit (PLC) technology for high reliability and performance.

  • Compact and rugged design.

  • Available without connectors for custom termination.

2.Optical Specifications

• Split Ratio:

  • 1x2 (default), customizable to other ratios (e.g., 1x4, 1x8, 1x16).

• Wavelength Range:

  • 1260 nm to 1650 nm (Full C, L, and O bands).

• Insertion Loss:

  • Typical: 3.6 dB.

  • Maximum: 4.0 dB.

  • Uniformity:

• • 0.8 dB .

• Polarization Dependent Loss (PDL):

  • 0.2 dB.

• Return Loss:

  • 55 dB.

• Directivity:

  • 55 dB.

3.Environmental Specifications

• Operating Temperature:

  • -40C to +85C.

• Storage Temperature:

  • -40C to +85C.

• Relative Humidity:

  • 5% to 95% (non-condensing).

4.Mechanical Specifications

• Fiber Type:

  • Compatible with single-mode fiber (SMF-28 or equivalent).

• Fiber Length:

  • Customizable (standard length: 1.0 meter).

• Fiber Diameter:

  • 250 m (bare fiber), 900 m (loose tube), or 2.0 mm (tight buffer).

• Package Type:

  • Bare fiber or modular box (optional).

• Dimensions:

  • Bare fiber: Compact and flexible.

  • Modular box: Customizable based on application.

• Weight:

  • Bare fiber: < 50 grams.

  • Modular box: < 100 grams.

5.Reliability and Durability

• Lifetime:

  • 25 years (under typical operating conditions).

• Mechanical Durability:

  • Resistant to vibration, shock, and temperature fluctuations.

6.Safety and Compliance

• Safety Standards:

  • Compliant with IEC 60825-1 (Laser Safety).

• Environmental Compliance:

  • RoHS compliant (Restriction of Hazardous Substances).

7.Ordering Information

• Base Unit: Fiber PLC Splitter 1x2 (Without Connector).

• Optional Customizations:

  • Custom split ratios (e.g., 1x2, 1x4, 1x8, 1x16).

  • Custom fiber length and diameter.

  • Modular box packaging.
